1. Ti high-end omap3530 processor is adopted, and the processing speed is up to 1GHz;

2. Philips mobile phone design technology is adopted, which is faster and more power-saving;

3. High resolution wide viewing angle 480x320 4.3 "TFT" LCD display;

4. SRAM: 96m, can be upgraded to 2G; Flash: 64M flash memory;

5. Configure the touch screen parameters on the setup page;

6. Display: 480x320tfm true color LCD; Brightness: 350cd / m2; Contrast: 250:1;

7. Display color: 262K (18bit, 262144); Visual angle: horizontal plus or minus 60 degrees, vertical plus or minus 35 degrees;

8. Touch panel type: four wire resistance type;

9. Accuracy of touch screen: 2pixel; Minimum service life of touch panel: 10000000 times;

10. Maximum power consumption: 3.6W, maximum brightness;

11. Communication mode: RS-232 or RS485; Control distance: 30m;

12. Control identification: ID address 00 ~ F0, software setting;

13. Standby time: 1 ~ 99 minutes; Sleep time: 1 ~ 99 minutes;

14. Power supply: 1A@12V DC, provided by kt-net;

15. USB project download;
