1. Power supply: 220VAC

2. Maximum power consumption: 10W

3. Signal interface type: RCA socket, component video y, Pb, PR, HDMI

4. Control mode: manual / automatic (232)

5. Number of channels: 6 in and 1 out (2 synchronous outputs)

6. Input and output

Video input interface: RCA socket 6 * 3

Video output interface: RCA socket 2 * 3

7. Automatic switching control port: 232 serial port * 1

8. Video bandwidth: 250MHz

9. Signal to noise ratio: 70dB

10. Bright signal isolation (crosstalk): < - 85dB (10MHz)

11. Color signal isolation (crosstalk): < - 65dB (10MHz)

12. Video input / output: amplitude (level): 2 Vp-p

13. Gain: 0dB

14. External dimension: 483 × three hundred and twenty-three × 90mm

15. Color: Black

16. Installation: 19 inch standard cabinet (2U)

1. It has 6 groups of video signal inputs and can connect 6 cameras;

2. Any group of videos can be switched automatically or manually;

3. After the preset of the system, the signal can be switched automatically

4. It has 6 channels of Y / Pb / PR analog HD color difference component input;

5. It has 2 channels of Y / Pb / PR analog HD color difference component output (synchronous);

6. It has 6 channels of HDMI Digital HD input interface;

7. It has 1 channel of HDMI Digital HD output interface;
