1. Display size: 7 inches

2. Resolution: 1024x600

3. Touch resistance

4. Master CPU: Samsung 4418 4-core cortex ?- A9

5. Startup speed: 22 seconds

6. Operating system: Linux

7.DSP：ADSP-21489 400Mhz

8. Analog input: 16CH (14mic + 2line)

9. Digital input: S / P DIF, optical fiber

10. Digital output: AES EBU

11. USB: recording / playing, playing format ape, FLAC, MP3, wav

12. Analog output: L / R + 6bus + 2aux + headphone (L / R)

13. Bottom noise: - 89dbu no recording weight (AP 515 test)

14. Distortion: 0.005% @4dbu 20 ~ 20KHz

15. Sex noise ratio: - 106db, no recording weight

16. Dynamic range: 106db

17. Frequency response: 20Hz ~ 20KHz ± 0.3dB

18. Maximum input / output level: 18dbu (6.2vrms) balanced

19. DCA: Yes

20. Chinese English interface: Yes

21. Electric pusher: 13

22. IPad control: Yes

23. Effector: 2 Effects

24. Feedback suppressor: 16 independent

25. Speaker Manager: Yes

26. Ethernet: 100M

27. RS-232 protocol: Yes

28. WiFi: 150m (optional)

29. USB mouse: support

30. Dimension (w * D * h): 450x460x168mm

31. Power supply: AC 100v-240v; 50/60Hz  55W

32. Net weight: 10.2kg

33. Gross weight: 12kg

34. Package size: 600x500x300mm

1.7-inch resistive touch screen, 1024x600 resolution

2.13 100mm electric pushers

3. The Chinese and English interfaces can be switched at any time without restart

4. Built in USB recording and playback function

5. It can play ape, FLAC, MP3 and wav lossless audio formats

6. The USB player can recognize Chinese song names

7. Built in 16 channel independent feedback Suppressors

8. Integrated speaker Manager

9. Open the third-party control protocol TCP / IP and RS-232 control instructions

10. With 2 DCAS

11. IPad touch screen full function control, real-time data synchronization

12. Optional WiFi hotspot

13. Support simultaneous control of 8 terminals

14. Built in 2 effector modules

15. Arm firmware and DSP firmware can be upgraded through network or USB resistance disk

16. Each input channel has 4 sections of parameter equalization, noise gate, feedback suppressor, high-low pass, compression and inversion

17. Each output channel has 8-segment parameter equalization, high-low pass, compression, inversion and 1-second delay

18. Output channel L / R, 6bus, 2aux, headphone (L / R)

19.6 bus and 2 aux mix bus can select before and after push (pre / post)

20. It supports 100 sets of scene preset functions, and can export and import USB memory for data backup

21.32 PEQ mode storage

22. Built in signal generator: sine wave, pink noise, white noise

23. Channel parameter copy function, the same channel can quickly copy data

24. Wiring mode: balanced input and output XLR

25.8 pusher groups, 1 system mute key and 3 fast mute keys

26. With panel locking key (to prevent misoperation)

27. Channel name can be customized
