產品型號：ZR-M260
Professional power amplifier with high efficiency, energy conservation and environmental protection
2U standard chassis combined with iron panel
Using patch process
Single group power supply and relay output are adopted
Automatic limiting function
Front and rear convection, intelligent stepless speed regulation
Short circuit protection \\ DC protection \\ over temperature protection \\ overload protection \\ soft start
Performance parameters:
Voltage gain 38dB
Signal to noise ratio (a weighted) > 90dB
Channel isolation 57db
Common mode rejection ratio 74dB
Frequency response (20Hz-20KHz + / - 1dB)
Damping coefficient > 200@1KHZ
Distortion (1kHz) < 0.05%
Input impedance balanced 20K Ω unbalanced 10K Ω
Power cord specification 10A / 250V power cord 3 * 1.5mm2
Body size 482 * 88 * 282mm
Power requirements 220V + / - 10% 50 / 60Hz
