Function introduction:

1 channel of 6.3 composite XLR analog signal input,

1 channel link signal output 1 Built in IP network decoding module;

2.3-channel microphone input, 2-channel line input, 1 microphone with priority;

3.70v/100v/4-16 Ω output;

4.800w power, sensitivity 200mV, signal-to-noise ratio 95dB, output impedance 8 Ω, distortion rate 1%;

5. Machine size: 483 * 90 * 340 (mm);

6. It has multiple protection functions of output short circuit, overload and overheating;

7. The power supply of the power amplifier is automatically managed. It can be turned on automatically when playing music on the network, or it can be turned on manually.

Input sensitivity: balance signal 0.77v, Unbalanced signal is 1.4V, 2 in 4 out 48K / 24bit high-performance DSP audio processor USB computer online function, Convenient and fast Protection function: short circuit, overload, over temperature, amplitude limiting, startup delay, high-strength thickened aluminum alloy heat dissipation panel
