Host parameters:

1. Host operating voltage: DC -- 12v-14v2a

2. Working current: 600mah

3. Power consumption: 8W

4. Receiving sensitivity: - 105dbm

5. Signal to noise ratio: S / N: > 100dB

6. Distortion thd: < 0.01%

7. Audio output voltage: 0.3V

8. Adjacent frequency interference suppression: > 60dB

9. Receiver: 44.4mm high * 483mm wide 185mm deep

Microphone parameters:

1. Microphone type: moving coil type

2. Microphone directivity: cardioid directivity

3. Pickup sensitivity: > - 20dbm (1V)

4. Transmitting power: > + 10dBm (10mwh)

5. Microphone power consumption: 110mha

6. Effective distance: obstacle free straight line 60m (diversity mode 120m)

7. Audio response: 50Hz-18KHz

8. Frequency stability: + - 0.001%

9. Anti electromagnetic wave of mobile phone: Yes

10. Working frequency: 610-780mhz

11. Frequency stability: ± 0.002%

12. FM maximum modulation frequency deviation: ± 45khz

13. Communication command: controlled by microcomputer CPU

14. Power reminder: intelligent battery undervoltage warning display

15. Circuit index: PLL PLL frequency synthesis technology, dynamic audio compression and automatic level control circuit

16. Noise lock squelch control + voice code navigation lock squelch control

1. (built in voice control matrix system) support multiple full open modes, greatly improve the ability to prevent howling, and make the human voice more fidelity without adding feedback device

2. (any two-way can switch to true diversity reception mode) so that the microphones distributed at the far end and the chairman microphone have better stable performance

3. (with Chairman priority function) make the meeting better controlled

4. The unit adopts OLED HD color display

5. The unit uses 2000mha lithium battery, which can work continuously for more than 10 hours and stand by for more than 20 hours

6. Exquisite short rod design, the line of sight pickup distance can reach 80cm, clear and clear

7. Multiple machines can be connected in series to realize the multi person full open mode. A chairman unit can prohibit all representative units from automatically recovering after 6 seconds

8. Equipped with automatic frequency scanning function, the host radar scans the surrounding radio waves and automatically selects a frequency without interference
